Stratasys and Ricoh USA collaborate to provide 3D printed multi-color anatomical models for medical structures

November 3, 2021, Industrial3D printingMachine manufacturer Stratasys has partnered with digital services company Ricoh USA to provideMedical treatmentInstitutions provide medical points3D printingAnatomical model service.In this collaboration, Stratasys’3D printingTechnology will be integrated into the workflow of Ricoh USA’s Ricoh Medical Platform to increase medical institutions andclinicalDoctor right3D printingUse of medical models.This product is designed to operate3D printingThe medical institution of the facility eliminates staffing problems,TrainingObstacles such as requirements and budget constraints.

Gary Turner, general manager of the Ricoh 3D medical department, said: “So far, the opportunity to obtain anatomical models at medical points is limited to large hospitals and medical institutions. Our cost-effective solution has expanded the scope of use in medical institutions of all sizes. In cooperation with Stratasys, through integration with IBM Watson Health and our continued commitment to innovation, we are able to provide these models to any organization that uses IBM iConnect Access.”

△Anatomical model of the spine printed on the Stratasys J750 digital anatomy printer. Image source: Business Wire.

3D printingAnatomical model

Anatomical model making is3D printingA relatively mature application in the field of healthcare, many medical centers and hospitals are already operating their own internal3D printingfacility.
When with3D scanningWhen combined with X-ray technology,3D printingThe anatomical model can provide more accessible and personalized options than cadavers, and can also help
surgical
Doctors are better prepared for the upcoming body
Operation
, Thereby increasing the success rate of treatment.
3D printingtechnologyIt can also make anatomical models with color fidelity that was previously unattainable, while saving three to four hours of operation time, in some cases saving up to 20,000 pounds per operation.

△J750 digital anatomy printer can produce imitating bones,Blood vesselAnd organ tissuebiologyModel of mechanical properties. The photo is from Stratasys.

Anatomy of Stratasys3D printingability

Stratasys3D printingThe anatomical models created by the technology have helped medical service providers improve their surgical preparations and allowed medical device manufacturers to test and train new devices for medical professionals.
Stratasys’ J750 Digital Anatomy3D printingThe machine can produce biomechanically accurate models that replicate porous bone structure, fibrous tissue, ligaments and soft cardiac tissue. This printer utilizes three special materials developed by Stratasys; TissueMatrix for replicating heart tissue, GelMatrix support material for model cavity, and BoneMatrix for replicating bone structure.
Since its first launch in 2016, the capabilities of the J750 have been aimed at the production of anatomical models, supported by the quality and color range provided by Stratasys’ PolyJet technology. In 2019, J750 was verified by Pantone, a global color authority, which also led Stratasys to
standard
The supplier’s color management system is integrated into the printer’s workflow.Soon after, the company released the J750 medical upgrade and released the J750 digital anatomy to the public3D printingmachine.
In December 2020, Stratasys further improved the functions of the J750 digital anatomy printer, including biomechanically accurate
orthopedics
Applications such as bones and ligaments.

The technology provided by Stratasys for anatomical models is not over. The company launched a new full-color J5 MediJet in June this year. 3D printingmachine. J5 MediJet is specifically designed for medical applications, including patient-specific anatomical models and surgical guides, and is compatible with a series of sterilizable and biocompatible3D printingResin compatible.

△On J5MediJet3D printingMulticolor medical model. Picture from Stratasys.

Ricoh 3D Medical Platform

The Ricoh 3D medical platform is an end-to-end workflow designed to simplify the design, development and production of anatomical models. The workflow utilizes the IBM iConnect Access diagnostic and medical image exchange platform updated by IBM Watson Health, the medical department of the technology consulting company IBM.

Earlier this year, Ricoh America and IBM Watson Health cooperated3D printingThe basis of the function is integrated into the platform, which will enable IBM iConnect Access users to use the patient’s medical imaging data directly from the platform3D printingCreate realistic anatomical models. Through the new cooperation with Stratasys, Ricoh will use J750 Digital Anatomy and J5 MediJet 3D printingMachine to make models for its Ricoh 3D for Healthcare platform.

The Ricoh 3D medical platform can currently be provided to medical institutions in two different ways. The first is the medical point option. Stratasys printers and Ricoh America’s management service personnel manage the entire printing process on site, in line with the company’s quality management system and good production practices.

The second option is on-demand services, medical institutions can order and get3D printingOf the anatomical models and shipped directly to them. Both programs meet HIPAA standards and are said to be easy for medical staff to use.

Through their various partnerships, Stratasys, Ricoh America, and IBM Watson Health are seeking to overcome the desire of medical institutions to operate their own3D printingMany obstacles faced by facilities, such as budget and staffing issues, training requirements, and HIPAA, quality, and IT compliance.After solving these obstacles, the partners hope to improve3D printing, The accessibility of the patient’s specific anatomical model.

△iConnectAccess 3D model viewer. The picture comes from IBM.

Scott Drikakis, head of the medical field of Stratasys, said: “Through cooperation with Ricoh, we give medical institutions the opportunity to obtain patient care tools that they may not have available before. With the Ricoh 3D medical platform, medical institutions can manage services on-site or on-demand. Way, using the most advanced technology to easily generate patient-specific anatomy3D printingModel.This will demonstrate the clinical and economic benefits of anatomical models while simplifying the establishment of3D printingThe challenge of the project. “

(Editor in charge: admin)
