China3D printingNet November 17th, with continuous reinforcing fibers (such as carbon fiber)3D printingIt has only just begun to become popular, and many start-up companies are developing their own unique methods for this concept. Many of these companies are still in the R&D or testing stage.However, the Dutch company CEAD is already manufacturing and shipping its large reinforcing fibers3D printingIt has already developed a follow-up system in cooperation with Siemens, which will be exhibited at Formnext 2019: AM Flexbot.
The company’s first printer, CFAM Prime, has a huge structure of 4mx2mx1.5m, according to China3D printingWang understands that it can print thermoplastics reinforced with continuous glass or carbon fiber at an average speed of 15 kg/h. In order to maintain accuracy when depositing at such speeds, the system is controlled by Siemens Sinumerik 840D sl.
The company’s new technology, AM Flexbot, expands the partnership between CEAD and Siemens, thus realizing3D printingProcess, the process uses a large industrial manipulator as a moving platform. The system has a CEAD single-screw extruder unit, which is installed on a Comau robot arm, all controlled by Siemens Sinumerik CNC through Run MyRobot / Direct Control software.
CEAD is used for the parts of the small pedestrian bridge that the company is manufacturing.
CEAD to maintain the accuracy required to accurately deposit the material to the final shape before the milled part is completed. AM Flexbot is available for purchase now, but CEAD’s goal is to expand its feature set.If the system can do it at the same time3D printingAnd milling, you can imagine other functions it might have. This may include performing quality control metrology after printing, using robotic fixtures to add external components, or working with other robotic arms to create larger structures.
CEAD co-founder and director of operations Lucas Janssen (Lucas Janssen) said to the product: “By using Siemens Sinumerik Run MyRobot / Direct Control and Comau robot arms in the latest solutions, we are able to provide scalable modularity. System to meet customer needs because many different functions can be added at any time. We are very happy to cooperate with Siemens and its reliable products.”
CEAD is not alone in the fiber reinforced or robotic arm space.In the former case, companies like AREVO, Impossible Objects, Markforged, Desktop Metal, Anisoprint and Continuous Composites are only engaged in fiber reinforcement.3D printingOr a few companies that can immediately obtain commercial products.For robotic arms, only 3D Systems, MX3D, Stratasys and EnvisionTEC use robotic arms for3D printingOr a commercial company with commercial solutions. In these two areas, countless research projects are being implemented, so CEAD will find itself with a lot of company support in the near future.
China3D printingNet original article!
(Editor in charge: admin)
